- TUNER SEND ACTIVE WHEN LATCHING ‘HOLD’ BUTTON IS PRESSED.
- TUNER SEND CAN ALSO SERVE AS AN A/B SELECTOR OPTION.
- COMPLETELY PASSIVE/TRUE BYPASS SWITCHING WITH ZERO EFFECT ON TONE.
- SUITABLE TO USE WITH ANY INSTRUMENT OR DEVICE THAT CAN BE CONNECTED VIA 1/4"/6.35MM JACK CABLE.
- POPLESS SWITCHING.
- L.E.D INDICATOR POWERED BY STANDARD 9-18V DC
(NEGATIVE CENTER).
- STANDARD 2.1MM POWER SOCKET FOR REGULAR PEDAL POWER SUPPLIES & DAISY-CHAINS. (BATTERY IS DISCONNECTED WHEN POWER JACK IS INSERTED). POWER IS FOR L.E.D.S ONLY.
- CURRENT DRAW (APPROX): <0.5MA
- BATTERY CLIP OPTION INSIDE (POWER SAVING WHEN INPUT JACK IS ABSENT).
- SATIN VINTAGE-STYLE ACRYLIC FINISH.
- VINTAGE STYLE AMBER LED INDICATOR.
- ROBUST & COMPACT DIE-CAST ALUMINIUM CHASSIS.
- FULLY SHIELDED UNIT TO ELIMINATE INTERFERENCE AND NOISE.
A SIMPLE MASTER CONTROL SWITCH TO END ANY PEDAL CHAIN,
THIS SIMPLE DEVICE WILL MUTE THE SIGNAL, ELIMINATING NOISE DURING TUNING OR WHILST EQUIPMENT IS ON STANDBY READY TO GIG.
WHEN 'ACTIVATED', THE OUTPUT IS MUTED AND THE SIGNAL REDIRECTED TO THE TUNER SEND; GREAT IF YOU ARE A TRUE BYPASS FAN AND WANT THAT BUFFERED TUNER OUT OF THE WAY.
THE (RIGHT) 'STAB' FOOTSWITCH IS NON-LATCHING AND CAN BE USED TO CREATE MANUAL TREMOLO & GLITCHING EFFECTS. WHEN THE (LEFT) LATCHING ‘MUTE' SWITCH IS PRESSED, THE SIGNAL IS MUTED AND THE ‘STAB' SWITCH WILL MOMENTARILY 'ALLOW' THE SIGNAL THROUGH. CONVERSELY, WHILST THE LATCHING 'MUTE' IS DEACTIVATED/UNMUTED, THE 'STAB' WILL MOMENTARILY MUTE.
BEST PLACED BEFORE AMBIENCE EFFECTS TO PRESERVE TAILS.
